For model Master 505K, Bang & Olufsen (B&O); Struer:
Master 505K

Country:  Denmark
Manufacturer / Brand:  Bang & Olufsen (B&O); Struer
Brand

B&O
Year: 1949/1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UAF42 UAF42 UCH42 UBL21 UM4
schematic requested
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage AC/DC-set / 110-240 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Master 505K - Bang & Olufsen B&O; Struer
Material Wooden case
Shape Tablemodel with Push Buttons.
Notes Klappskala

Model page created by Hermann Jung. See "Data change" for further contributors.
