• Country
• Belgium

• Manufacturer / Brand
• Bell Telephone Mfg. Co. (Radiobell); Antwerp

• Year
• 1957/1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 203326

• • Brand: Radiobell

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• UF41 UCH42 UAF42 UL41 UY41

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set / 110/130; 220/250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Radiobell Nassack RB209 - Bell Telephone Mfg. Co.

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 380 x 255 x 180 mm / 15 x 10 x 7.1 inch

• Notes
• Available in different colors.

  See also model 209S.

  Chassis = Sancy RB200. Stewart RB431 and Pacha RB433 have the same chassis.

• Source of data
• -- Original prospect or advert
