A253; Blaupunkt Ideal, (ID = 2360100) Car Radio
Blaupunkt Ideal,: A253 [Car Radio] ID = 2360100 1400x848
Select picture or schematic to display from thumbnails on the right and click for download.
For model A253, Blaupunkt (Ideal), Berlin, später Hildesheim:
A253 mit Opelblende

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1953/1954 Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 4: ECH42 EAF42 EAF42 EL41
Semiconductors (the count is only for transistors) SM702/1Z or. SM702/2Z B250C100
Main principle Superheterodyne (common); ZF/IF 450 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: A253 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 183 x 76 x 168 mm / 7.2 x 3 x 6.6 inch
Notes
Price in first year of sale 285.00 DM
External source of data Erb
Source of data Kat.d.Rundf.GrossH.1953/54
