A52E; Blaupunkt Ideal, (ID = 156906) Car Radio
Blaupunkt Ideal,: A52E [Car Radio] ID = 156906 933x568
Select picture or schematic to display from thumbnails on the right and click for download.
For model A52E, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1953/1954 Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 4: ECH42 EAF42 EAF42 EL41
Semiconductors (the count is only for transistors) SM30/12z or. SM30/13z Tr.Gl.=Metal-rectif.
Main principle Superheterodyne (common); ZF/IF 473 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 3 W (unknown quality)
from Radiomuseum.org Model: A52E - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 183 x 76 x 168 mm / 7.2 x 3 x 6.6 inch
Notes mechanischer Zerhacker Maße Zerhackerteil 187x117x73mm
Net weight (2.2 lb = 1 kg) 5.4 kg / 11 lb 14.3 oz (11.894 lb)
Price in first year of sale 298.00 DM
External source of data Wiesmüller
Source of data Lange, Schaltungen der Funkindustrie
