Automatic Direct Drive P-150 7.629.950
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1979/1980
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 120552
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
Q: Blaupunkt, Service-Unterlagen
Q: Blaupunkt, Service-Unterlagen '79
Q: Blaupunkt, Produkt-Katalog '80
Q: Blaupunkt, Produkt-Katalog '80
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 7
- Wave bands
- - without
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Various materials
- from Radiomuseum.org
- Model: Automatic Direct Drive P-150 7.629.950 - Blaupunkt Ideal, Berlin,
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 435 x 145 x 370 mm / 17.1 x 5.7 x 14.6 inch
- Notes
-
Direktantrieb, 33 und 45 U/min,
S-förmiger Tonarm mit Antiskatingeinrichtung,
Tonabnehmer: ATN-71.Halbleiter einmal je Type gelistet.
- Net weight (2.2 lb = 1 kg)
- 6.4 kg / 14 lb 1.6 oz (14.097 lb)
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Iven Müller. See "Data change" for further contributors.
