Derby City 7.657.010

Derby City 7.657.010; Blaupunkt Ideal, (ID = 296152) Radio

Derby City 7.657.010; Blaupunkt Ideal, (ID = 296153) Radio

Derby City 7.657.010; Blaupunkt Ideal, (ID = 296154) Radio

Derby City 7.657.010; Blaupunkt Ideal, (ID = 296155) Radio

Derby City 7.657.010; Blaupunkt Ideal, (ID = 1826638) Radio

Derby City 7.657.010; Blaupunkt Ideal, (ID = 1826639) Radio

Derby City 7.657.010; Blaupunkt Ideal, (ID = 1974535) Radio

Derby City 7.657.010; Blaupunkt Ideal, (ID = 2021921) Radio

Derby City 7.657.010; Blaupunkt Ideal, (ID = 2021922) Radio

Derby City 7.657.010; Blaupunkt Ideal, (ID = 2021923) Radio
Derby City 7.657.010; Blaupunkt Ideal, (ID = 300605) Radio Derby City 7.657.010; Blaupunkt Ideal, (ID = 300602) Radio
Derby City 7.657.010; Blaupunkt Ideal, (ID = 300601) Radio Derby City 7.657.010; Blaupunkt Ideal, (ID = 1612999) Radio
Derby City 7.657.010; Blaupunkt Ideal, (ID = 1613000) Radio Derby City 7.657.010; Blaupunkt Ideal, (ID = 1613001) Radio
Derby City 7.657.010; Blaupunkt Ideal, (ID = 1788191) Radio Derby City 7.657.010; Blaupunkt Ideal, (ID = 1788192) Radio
Derby City 7.657.010; Blaupunkt Ideal, (ID = 1982486) Radio Derby City 7.657.010; Blaupunkt Ideal, (ID = 1982488) Radio
Use red slider bar for more.
Derby City 7.657.010; Blaupunkt Ideal, (ID = 300605) Radio
Blaupunkt Ideal,: Derby City 7.657.010 [Radio] ID = 300605 868x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Derby City 7.657.010, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1976–1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 13:
Main principle Super-Heterodyne (Super in general); ZF/IF 455/10700 kHz
Tuned circuits 5 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220 / D: 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 0.7 W (unknown quality)
from Radiomuseum.org Model: Derby City 7.657.010 - Blaupunkt Ideal, Berlin,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 300 x 210 x 90 mm / 11.8 x 8.3 x 3.5 inch
Notes Blaupunkt Derby City (7.657.010).
Net weight (2.2 lb = 1 kg) 2.6 kg / 5 lb 11.6 oz (5.727 lb)
Collectors' prices
Source of data Handbuch VDRG 1977/1978
Mentioned in Handbuch VDRG 1976/1977
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Richard Winter. See "Data change" for further contributors.
