Frankfurt Stereo 7.639.695 ab 2681001

Blaupunkt (Ideal), Berlin, später Hildesheim

  • Year
  • 1969/1970
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 27768
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 25
  • Main principle
  • Superhet with RF-stage; ZF/IF 460/10700 kHz
  • Tuned circuits
  • 8 AM circuit(s)     13 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Frankfurt Stereo 7.639.695 ab 2681001 - Blaupunkt Ideal, Berlin,
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 178 x 50 x 147 mm / 7 x 2 x 5.8 inch
  • Notes
  • Halbleiter teilweise mehrfach vorhanden.
    Erstes Blaupunkt Stereo-Autoradio. Stereo-NF-Verstärker mit 2 Gegentakt-Endstufen je 4 W.

    Antennenanpassung rückseitig einstellbar (unterhalb Lautsprecher-Anschluss).
    Stereo-Balance über Trimmer an rechter Seitenwand einstellbar.

  • Net weight (2.2 lb = 1 kg)
  • 1.6 kg / 3 lb 8.4 oz (3.524 lb)
  • External source of data
  • erb
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Literature/Schematics (2)
  • Funkschau (12/1969, S. 359 - Stereo im Auto, und 8/1970, S.237 ff., Vorstellung und Schema)
  • Literature/Schematics (3)
  • Handbuch für Rundfunk, Fernsehen, Phono 1969/70 (Thiele, Verlag Funk-Kurier)

 Collections | Museums | Literature

 Forum

Forum contributions about this model: Blaupunkt Ideal,: Frankfurt Stereo 7.639.695 ab 2681001

Threads: 1 | Posts: 1

Hallo liebe Sammlerkollegen, unter http://www.radiomuseum.org/r/blaupunkt_frankfurt_stereo.html gibt es jetzt eine ausführliche Funktionsbeschreibung eines Stereodecoders der Fa. Blaupunkt. Viele Grüße, H. zur Mühlen

Heiko zur Mühlen, 02.Jan.09
