BC183

Information - Help
ID = 36976

Country:
Europe
Brand: Common type Europe tube/semicond.
Tube type:  Transistor   Universal
Identical to BC183
Similar Tubes
Normally replaceable-slightly different:
  2N2713 ; 2N3565 ; 2SC1362 ; AF3_BRC ; BC107 ; BC148 ; BC168 ; BC171 ; BC207 ; BC237 ; BC238 ; BC254 ; BC382 ; BC547 ; BC548 ; BC582 ; BCY58 ; SC206 ; SE4001

Base Wires
Filament Solid State
Description NPN silicon transistor for general purpose.

Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip
5 x 5 x 4 mm / 0.20 x 0.20 x 0.16 inch
Weight 1 g / 0.04 oz
Literature -- Collector info (Sammler)   TTT Steidle 1981
  BC183: Funktechnik 15/69
Egon Strampe

BC183: Sammlung
Karlheinz Fischer


BC183: TVT 1969 Verlag Nolde Dachau
Günther Stabe


BC183: Texas Instruments
Thomas Günzel


Usage in Models 1= 1967 ; 5= 1968 ; 2= 1969? ; 8= 1969 ; 3= 1970?? ; 12= 1970 ; 2= 1971 ; 1= 1972?? ; 2= 1972 ; 1= 1974?? ; 1= 1974 ; 1= 1975?? ; 1= 1975? ; 1= 1977? ; 1= 1978 ; 1= 1979?? ; 1= 1980

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):44
