Hamburg ATR Alltransistor ab T 580001

Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 832272) Car Radio

Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 832273) Car Radio

Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 832275) Car Radio

Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 832276) Car Radio

Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 832277) Car Radio

Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 832278) Car Radio

Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 832283) Car Radio

Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 1540392) Car Radio

Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 1540393) Car Radio

Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 1540394) Car Radio
Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 2411515) Car Radio Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 194805) Car Radio
Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 1237580) Car Radio Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 1237577) Car Radio
Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 1237578) Car Radio Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 1237579) Car Radio
Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 1237581) Car Radio Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 1237576) Car Radio
Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 1237575) Car Radio Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 1540318) Car Radio
Use red slider bar for more.
Hamburg ATR Alltransistor ab T 580001; Blaupunkt Ideal, (ID = 2411515) Car Radio
Blaupunkt Ideal,: Hamburg ATR Alltransistor ab T 580001 [Car Radio] ID = 2411515 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Hamburg ATR Alltransistor ab T 580001, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1962/1963 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 6: AF117 AF117 AF117 OC75 OC74 AD130 BA100 OA79 OA79 OA79
Main principle Superheterodyne (common); ZF/IF 460 (452 or 473) kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Hamburg ATR Alltransistor ab T 580001 - Blaupunkt Ideal, Berlin,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 183 x 82 x 168 mm / 7.2 x 3.2 x 6.6 inch
Notes

Omnimat-Wählautomatik mit 5 Stationstasten.

Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
Price in first year of sale 235.00 DM
External source of data Erb
Source of data Handbuch VDRG 1962/1963
Literature/Schematics (1) -- Original-techn. papers.


All listed radios etc. from Blaupunkt (Ideal), Berlin, später Hildesheim
Here you find 3229 models, 2899 with images and 2215 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Blaupunkt Ideal,: Hamburg ATR Alltransistor ab T 580001
Threads: 1 | Posts: 1
Hits: 1217     Replies: 0
blaupunkt: Serie T ab 580001; Hamburg ATR Alltransistor
Ernst Erb
15.Jan.13
  1

From guest Ed Robles, Ferreira do Zezere, Portugal I received the following repair message:


-  It was playing for about 15 minutes, and than it stopped playing, after some hours the same happened.

-  We found out that one of the 3 transistors AF117 caused this problem, we replaced the transistor by another of the same type (a used one). With this trasistor the radio kept playing a litle longer, but after about an hour it also stopt playing.

-  This type of transistor has 4 connections, one off is connected with the metal cage of the transistor, and is meant to reduce interference.

-  By disconnecting this 4th wire from the printed-circuit, the problem was solved, we also disconnected this wire of the other 2  AF117 transistors, just in case.

-  For so far I don’t hear any difference of interference.


Blaupunkt Ideal,: Hamburg ATR Alltransistor ab T 580001
