STG2091 7.621.400; Blaupunkt Ideal, (ID = 435658) Radio
Blaupunkt Ideal,: STG2091 7.621.400 [Radio] ID = 435658 933x350
Select picture or schematic to display from thumbnails on the right and click for download.
For model STG2091 7.621.400, Blaupunkt (Ideal), Berlin, später Hildesheim

Country:  Germany
Manufacturer / Brand:  Blaupunkt (Ideal), Berlin, später Hildesheim
alternative name

Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
Brand
Rotstern
Year: 1971–1973 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 35:
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220-240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 30 W (unknown quality)
from Radiomuseum.org Model: STG2091 7.621.400 - Blaupunkt Ideal, Berlin,
Material Modern plastics (no Bakelite or Catalin)
Shape Book-shelf unit.
Dimensions (WHD) 580 x 124 x 265 mm / 22.8 x 4.9 x 10.4 inch
Notes Vollstereo, NF-Verstärker mit zwei Endstufen je 15 W (Sinus), bei KW1 = 8 Kreise.
Net weight (2.2 lb = 1 kg) 7.6 kg / 16 lb 11.8 oz (16.74 lb)
Price in first year of sale 748.00 DM
Collectors' prices
External source of data Erb
Source of data Handbuch VDRG 1971/1972
