Radio-Phono-Kombination PK-G5/7 Ch= RC7
Braun; Frankfurt
- Country
- Germany
- Manufacturer / Brand
- Braun; Frankfurt
- Year
- 1958/1959
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 191792
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 12 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
- Loudspeaker
- 2 Loudspeakers
- Power out
- 7 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radio-Phono-Kombination PK-G5/7 Ch= RC7 - Braun; Frankfurt
- Shape
- Console with Push Buttons.
- Dimensions (WHD)
- 950 x 330 x 370 mm / 37.4 x 13 x 14.6 inch
- Notes
- Phono-Chassis: Braun PC3
Lautsprecher: 1 perm.-dyn., 26 x 18 cm, 1 perm.-dyn., 10 cm.
3 Klangtasten. 7-W-Gegentakt-Endstufe.
Höhe mit Untergestell 66 cm.
Ausführung: Ahorn, natur mattiert.
- Net weight (2.2 lb = 1 kg)
- 19.8 kg / 43 lb 9.8 oz (43.612 lb)
- Price in first year of sale
- 580.00 DM
- Source of data
- -- Original-techn. papers.
- Mentioned in
- HdB d.Rdf-& Ferns-GrH 1958/59
- Author
- Model page created by Bernhard Nagel. See "Data change" for further contributors.
