Atelier T2

• Country
• Germany

• Manufacturer / Brand
• Braun; Frankfurt

• Year
• 1982–1987

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 147410

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 35

• Semiconductors
• 2SK168 2SK44 3SK73 2SK117 2SK118 2SC945 2SA733 2SC1815 2SA1015 2SC1674 2SC2240 2SC1675 2SC2001 2SD325 TPS606 KV1225 SVC211 1N60P 1S2075 DS135 RD3R0EB SLP244B PR5533T SLP253B SEL1110 SEL1321 TA7060 JR2434 AN6135 TC9147 TD6301 CD4081 CD4001 TD6104

• Main principle
• PLL, Phase-locked loop

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110-120; 220-240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Atelier T2 - Braun; Frankfurt

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 445 x 70 x 360 mm / 17.5 x 2.8 x 14.2 inch

• Notes

• Quarz-PLL-Synthesizer-AM/FM-Tuner mit automatischem Sendersuchlauf, 16 Stationstasten.

• Net weight (2.2 lb = 1 kg)
• 6 kg / 13 lb 3.5 oz (13.216 lb)

• Price in first year of sale
• 1,050.00 DM

• Source of data
• -- Original prospect or advert

• Literature/Schematics (1)
• Braun HiFi 1985/86 Seite 19

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
