Apex 730C

Apex 730C; Breville; Sydney (ID = 887767) Radio
Apex 730C; Breville; Sydney (ID = 2395553) Radio
Use red slider bar for more.
Apex 730C; Breville; Sydney (ID = 2395553) Radio
Breville; Sydney: Apex 730C [Radio] ID = 2395553 1400x2031
Select picture or schematic to display from thumbnails on the right and click for download.
For model Apex 730C, Breville; Sydney:
The Sun, Sydney, NSW, 20/6/1948, Page 13 (Trove Newspapers).

Country:  Australia
Manufacturer / Brand:  Breville; Sydney
Year: 1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH35 or ECH33 6U7G 6G8G 6V6GT 5Y3GT
Main principle Superheterodyne (common); ZF/IF 446 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 220; 240; 260 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
Power out
from Radiomuseum.org Model: Apex 730C - Breville; Sydney
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 29.5 x 33 x 12.5 inch / 749 x 838 x 318 mm
Notes

See also Table version, Acme Model 730T.

Price in first year of sale 40.75 AUS £
Circuit diagram reference Australian Official Radio Service Manual Vol. VII
Mentioned in Mingay's "Radio Diagram & I.F. Index
Literature/Schematics (1) Australian Official Radio Service Manual AORSM (Volume 7, 1949, Page 87.)

Model page created by Stuart Irwin. See "Data change" for further contributors.
