Fantasia 5HFK1

Fantasia 5HFK1; Canadian (ID = 2004142) R-Player

Fantasia 5HFK1; Canadian (ID = 2004140) R-Player

Fantasia 5HFK1; Canadian (ID = 2004141) R-Player

Fantasia 5HFK1; Canadian (ID = 2004143) R-Player
Fantasia 5HFK1; Canadian (ID = 1526589) R-Player
Use red slider bar for more.
Fantasia 5HFK1; Canadian (ID = 1526589) R-Player
Canadian: Fantasia 5HFK1 [R-Player] ID = 1526589 500x485
Select picture or schematic to display from thumbnails on the right and click for download.
For model Fantasia 5HFK1, Canadian Westinghouse, Hamilton:
Service documentation

Country:  Canada
Manufacturer / Brand:  Canadian Westinghouse, Hamilton
alternative name

Westinghouse Canada
Year: 1955/1956 Category: Sound/Video Recorder and/or Player
Valves / Tubes 5: 6SQ7 12AX7 6V6GT 6V6GT 5Y3GT
Main principle Audio-Amplification
Wave bands - without
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker 3 Loudspeakers
Power out 8 W (undistorted)
from Radiomuseum.org Model: Fantasia 5HFK1 - Canadian Westinghouse,
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 36 x 24 x 18.5 inch / 914 x 610 x 470 mm
Notes

The Westinghouse 5HFK-1 is a 5-tube amplifier console with 12 inch woofer and two 3.25 inch tweeters. Has a built in 4-speed BSR-UA8 record changer.
For 25 or 60 Hz depending on nameplate rating.

Mentioned in - - Manufacturers Literature
Literature/Schematics (1) Radio College of Canada (RCC) (1956-57 Supplement 39)

Model page created by Mark Hippenstiel. See "Data change" for further contributors.
