8 Transistor Deluxe All Wave 6512

Channel Master Corp.; USA

  • Year
  • 1959 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 133876

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 8
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Dry Batteries / 4 X 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.62 inch = 6.7 cm
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 8 Transistor Deluxe All Wave 6512 - Channel Master Corp.; USA
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 6.13 x 3.38 x 1.9 inch / 156 x 86 x 48 mm
  • Notes
  • "All Transistor All Wave Super". Made by Sanyo. SW 3.8 - 12.5 MHz. Sams photofact set 485 folder 6 date 5-60 features the Channel Master models 6512 and 6514 as the same schematic.

    Detachable Telescopic Ant. on top, Two Earphone Jacks on right side

    See also Sanyo 8S-P2.

    Made in Japan

  • Literature/Schematics (1)
  • Photofact TSM-7-29 and folder 485-6
  • Author
  • Model page created by Steven Sostrom. See "Data change" for further contributors.
