• Country
• France

• Manufacturer / Brand
• Cibot Radio; Paris

• Year
• 1957

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 138289

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 20

• Valves / Tubes
• ECC84 ECF80 EF80 EF80 EF80 EB91 EL84 EF80 EBF80 ECL80 ECL80 EF80 EL84 ECL80 6CD6 EY82 EY82 EY81 EY86 21ATP4

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 110; 117; 125; 220; 245 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Néo Télé 54-57 - Cibot Radio; Paris

• Notes
• Tube cathodique de 54cm à concentration électrostatique, multicanal.

• Literature/Schematics (1)
• Radio Constructeur et Dépanneur février, mars 1957

• Author
• Model page created by Raynal Aufils. See "Data change" for further contributors.
