Color Sound Graph CSA-002-001

Color Sound Graph CSA-002-001; Clarion Co., Ltd.; (ID = 2520952) Misc

Color Sound Graph CSA-002-001; Clarion Co., Ltd.; (ID = 2520306) Misc

Color Sound Graph CSA-002-001; Clarion Co., Ltd.; (ID = 2520945) Misc
Use red slider bar for more.
Color Sound Graph CSA-002-001; Clarion Co., Ltd.; (ID = 2520952) Misc
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Japan
Manufacturer / Brand:  Clarion Co., Ltd.; Tokyo
Year: 1973 ?? Category: Miscellaneous (Other, Various) - see notes
Semiconductors (the count is only for transistors) 4: 2SC829 2SC829 2SC829 2SC829
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Color Sound Graph CSA-002-001 - Clarion Co., Ltd.; Tokyo
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 10 x 16 x 8 inch / 254 x 406 x 203 mm
Notes

Audio-controlled lighting device with diamond-cut acryl front plate.
Uses 4 pilot lamps per color (12 in total).

Used in combination with HE-202 or HE-204.
See CSA-001-001 for full documentation.

Net weight (2.2 lb = 1 kg) 9.3 lb (9 lb 4.8 oz) / 4.222 kg
Mentioned in -- Original-techn. papers.

Model page created by Mark Hippenstiel. See "Data change" for further contributors.
