40AC

Columbia Graphophone Company Românâ S.A.; Bucuresti

Data
Forum
Pictures
Collections

  • Year
  • 1939 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 301735

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and more than two Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 110-240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 40AC - Columbia Graphophone Company
  • Shape
  • Tablemodel, low profile (big size).
  • Notes

  • 5 wavebands:
    LW: 750 - 200 m
    MW: 200 - 590 m
    SW1: 19 - 64 m
    SW2: 9.6 - 37 m
    SW3: 4.8 - 13.5 m

    Reception of Television sound on 6.5 - 7.5 m.

    See also model 41AC/DC.

  • Mentioned in
  • -- Original prospect or advert
