ELBE 007

Comercial Radio Bertrán; Electrónica Bertrán; ELBE; Barcelona

Data

Forum

Pictures

Collections

Country
Spain

Manufacturer / Brand
Comercial Radio Bertrán; Electrónica Bertrán; ELBE; Barcelona

Year
1967

Category
Television Receiver (TV) or Monitor

Radiomuseum.org ID
230478

Schematics

ELBE 007; Comercial Radio (ID = 2177141) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177142) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177143) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177144) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177145) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177147) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177148) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177149) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177150) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177151) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177152) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177153) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177154) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177155) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177156) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177157) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177158) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177159) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177160) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177161) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177162) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177163) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177164) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177165) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177166) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177167) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177168) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177169) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177170) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 2177171) Television — Comercial Radio ELBE 007 (3)

ELBE 007; Comercial Radio (ID = 1383674) Television — Comercial Radio ELBE 007 (2)
Anuncio La Vanguardia Española octubre 1968

ELBE 007; Comercial Radio (ID = 1383675) Television — Comercial Radio ELBE 007 (2)
Anuncio La Vanguardia Española octubre 1968

ELBE 007; Comercial Radio (ID = 2193510) Television — Comercial Radio ELBE 007 (2)
Anuncio La Vanguardia Española mayo 1967

ELBE 007; Comercial Radio (ID = 2806595) Television — Comercial Radio ELBE 007 (1)
Folleto de propaganda

ELBE 007; Comercial Radio (ID = 2806596) Television — Comercial Radio ELBE 007 (1)
Folleto de propaganda

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
2

Valves / Tubes
DY51 A28-13W

Number of Transistors
43

Semiconductors
AF118 AC125 AC126 AC127 AC128 OC44 OC45 BF115 BF155 AF121 AF126 BC107 ASY75 AD149 2N3731 SFD108 SFD112 SFR164 OA81 OA90 BA100 AA119 BZZ13 BYX10 BYX20/200R

Main principle
Superheterodyne (common)

Wave bands
VHF incl. FM and/or UHF (see notes for details)

Power type and voltage
Line / Storage batteries (perhaps also batteries) / 125; 220 / 12 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

Power out
1.2 W (undistorted)

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: ELBE 007 - Comercial Radio Bertrán;

Shape
Tablemodel, high profile (upright - NOT Cathedral nor decorative).

Notes
TRC: 11"

Anuncia 44 transistores pero el manual dice, y se cuentan, 43.

Listado un único semiconductor por tipo.

Literature/Schematics (1)
-- Original-techn. papers. (Anuncio La Vanguardia Española mayo 1967)

Author
Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
