• Country
• Great Britain (UK)

• Manufacturer / Brand
• Decca (Brand), Samuel (Barnett) & Sons, Ltd. & Decca Record Co., Ltd.; London

• Year
• 1951

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 165946

• • alternative name: Decca Gramophone || Decca Radio

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 28

• Valves / Tubes
• EF42 EF42 EF42 EF42 EB91 EF42 EF42 EB91 6L18 EB91 6F14 6L18 EB91 T41 Pen45 T41 EL38 6SN7GT 6SN7GT 6L18 6V6GT GZ32 EY51 EY51 EY51 EBC33 EL38 MW6-2

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 200-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Television Receiver 121 - Decca Brand, Samuel Barnett &

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 26 x 37 x 20 inch / 660 x 940 x 508 mm

• Notes

• Decca 121 Television Receiver;
  16" x 12" 405 lines b/w projection TV with single channel GB VHF band I tuner, console style with 1/2 size-doors, different cabinet finishes.

• Author
• Model page created by a member from A. See "Data change" for further contributors.
