1-A late

1-A; Drake, R.L. (ID = 1349675) Amateur-R 1-A; Drake, R.L. (ID = 1349676) Amateur-R
1-A; Drake, R.L. (ID = 1349677) Amateur-R 1-A; Drake, R.L. (ID = 1349678) Amateur-R
1-A; Drake, R.L. (ID = 1349679) Amateur-R 1-A; Drake, R.L. (ID = 1349680) Amateur-R
1-A; Drake, R.L. (ID = 1349681) Amateur-R
Use red slider bar for more.
1-A; Drake, R.L. (ID = 1349675) Amateur-R
Drake, R.L.: 1-A [Amateur-R] ID = 1349675 933x958
Select picture or schematic to display from thumbnails on the right and click for download.
For model 1-A late, Drake, R.L. Miamisburg, Ohio

Country:  United States of America (USA)
Manufacturer / Brand:  Drake, R.L. Miamisburg, Ohio
Year: 1959 ? Category: Amateur-Receiver (amateur bands, may include broadcast bands)
Valves / Tubes 13: 6BZ6 6BE6 6AB4 6BE6 6BQ7A 6BY6 6BZ6 12AU7 6BJ8 12AU7 12AQ5 12X4 12BA6
Main principle Superhet, double/triple conversion; ZF/IF 2900/1100 kHz
Wave bands Short Wave (SW only)
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 1-A [late] - Drake, R.L. Miamisburg, Ohio
Material Metal case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 171 x 279 x 381 mm / 6.7 x 11 x 15 inch
Notes covers 80 - 10m ham bands and WWV, LSB/USB;
internal speaker, crystal calibrator (operated by antenna trim control);
different AVC amp tube (6BJ8 instead of 6BF6) and circuitry, late models starting with serial no. 453.
Net weight (2.2 lb = 1 kg) 8.2 kg / 18 lb 1 oz (18.062 lb)
Price in first year of sale 299.00 $
Source of data Communications Receivers

Model page created by Martin Bösch. See "Data change" for further contributors.
