For model 300/S3 nur mit Tonabnehmer CDS320 (Stereo), Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

Country:  Germany
Manufacturer / Brand:  Dual, Gebr. Steidinger; St. Georgen/Schwarzwald
Year: 1958–1960 Category: Sound/Video Recorder and/or Player
schematic requested
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: 300/S3 [nur mit Tonabnehmer CDS320 ] - Dual, Gebr. Steidinger; St.
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 285 x 110 x 210 mm / 11.2 x 4.3 x 8.3 inch
Notes

Dual 300/S3 (Stereo)

Neuentwicklung ab 1958 mit dem Dual-Stereo-Kristallsystem CDS320 (Nadel DN3 55mN) deshalb auch CDS320/3 genannt,  20-16.000Hz, Tonarm ca 220mm, 4 Geschwindigkeiten: 16, 33, 45 und 78 UpM, automatischer Ausschalter und Kurzschließer für beide Stereo-Kanäle, automatische Treibradentlastung, Plattentellerbremse.

Mono - Ausführung mit CDS310 Tonabnehmersystem siehe: Dual_300

Nachfolgemodell, ab 1960, Dual_300A

Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Price in first year of sale 80.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1959/60 / Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original prospect or advert (Katalog 1959/60, Dual/PE Buch N. Kotschenreuther)
