• Country
• Germany

• Manufacturer / Brand
• Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

• Year
• 1970–1973

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 117315

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - For headphones or amp.

• from Radiomuseum.org
• Model: 420 - Dual, Gebr. Steidinger; St.

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 280 x 103 x 205 mm / 11 x 4.1 x 8.1 inch

• Notes

• 33/45 UpM; Stereo-Kristallsystem CDS 650, mit Nadel DN 6;
  Übertragungsbereich: 20···16000 Hz ± 3 dB.

• Net weight (2.2 lb = 1 kg)
• 2.3 kg / 5 lb 1.1 oz (5.066 lb)

• Price in first year of sale
• 88.00 DM

• Source of data
• Handbuch VDRG 1970/1971

• Literature/Schematics (1)
• -- Original-techn. papers. (Dual, Service-Unterlagen)

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
