CV 12A

CV 12A; Dual, Gebr. (ID = 397472) Ampl/Mixer CV 12A; Dual, Gebr. (ID = 397474) Ampl/Mixer
CV 12A; Dual, Gebr. (ID = 397475) Ampl/Mixer CV 12A; Dual, Gebr. (ID = 397476) Ampl/Mixer
CV 12A; Dual, Gebr. (ID = 397477) Ampl/Mixer CV 12A; Dual, Gebr. (ID = 397478) Ampl/Mixer
CV 12A; Dual, Gebr. (ID = 397479) Ampl/Mixer CV 12A; Dual, Gebr. (ID = 1025729) Ampl/Mixer
CV 12A; Dual, Gebr. (ID = 2028448) Ampl/Mixer CV 12A; Dual, Gebr. (ID = 2028449) Ampl/Mixer
Use red slider bar for more.
CV 12A; Dual, Gebr. (ID = 397472) Ampl/Mixer
Dual, Gebr.: CV 12A [Ampl/Mixer] ID = 397472 933x328
Select picture or schematic to display from thumbnails on the right and click for download.
For model CV 12A, Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

Country:  Germany
Manufacturer / Brand:  Dual, Gebr. Steidinger; St. Georgen/Schwarzwald
Year: 1968–1970 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 14:
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 150; 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 8 W (12 W max.)
from Radiomuseum.org Model: CV 12A - Dual, Gebr. Steidinger; St.
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 420 x 108 x 285 mm / 16.5 x 4.3 x 11.2 inch
Notes

Stereo-Verstärker 2 x 4 Watt (Dauerleistung) bzw. 2 x 6 Watt (Musikleistung).

Net weight (2.2 lb = 1 kg) 4.2 kg / 9 lb 4 oz (9.251 lb)
Price in first year of sale 248.00 DM
Mentioned in Dual Phonogeräte 1968/69
Literature/Schematics (1) Dual Programmübersicht 1969/70

Model page created by Michael Lienhop. See "Data change" for further contributors.
