Dual, Gebr.: HiFi-Stereo-Kompaktanlage KA50 [Radio] ID = 40955 642x444
Select picture or schematic to display from thumbnails on the right and click for download.
For model HiFi-Stereo-Kompaktanlage KA50, Dual, Gebr. Steidinger; St. Georgen/Schwarzwald

Country:  Germany
Manufacturer / Brand:  Dual, Gebr. Steidinger; St. Georgen/Schwarzwald
Year: 1971–1973 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 31: BF125 BF195 BF245 BF194 BC173 BC309 BC108 BC253 BC252 BC171 2N2218 2N2904 BD207 BB104 BA124 1N60 AA119 AA132 ZE2 BZY85 B40C2200 B30C300
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     18 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 130; 220; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 40 W (60 W max.)
from Radiomuseum.org Model: HiFi-Stereo-Kompaktanlage KA50 - Dual, Gebr. Steidinger; St.
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 420 x 225 x 377 mm / 16.5 x 8.9 x 14.8 inch
Notes

Dual HiFi Kompaktanlage KA 50

Vollstereo, NF-Verstärker mit zwei Endstufen je 20 Watt (Sinus) bzw 30 Watt (Musiklleistung), Rundfunkempfänger mit 5 Empfangsbereichen, FM-Empfindlichkeit < 1,5 µV für 26 dB Rauschabstand (Mono), 5 Stationstasten (FM)

Phono-Chassis Dual_1218  jedoch mit Magnetsystem Shure M 75Type D.

Abdeckhaube (Klapphaube) CH 20 im Lieferumfang

Gehäuse: Nußbaum; siehe auch KA50W in Schleiflack, weiß.

Jeder Halbleiter-Typ nur einmal gelistet.

Net weight (2.2 lb = 1 kg) 12.9 kg / 28 lb 6.6 oz (28.414 lb)
Price in first year of sale 1'298.00 DM
Collectors' prices
External source of data Erb
Source of data Handbuch VDRG 1971/1972 / Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original prospect or advert (Dual Programm 1971/72 und 1972/73)
