Inconnu / Unknown 1; Echo-Radio; Louvain (ID = 296925) Radio
Echo-Radio; Louvain: Inconnu / Unknown 1 [Radio] ID = 296925 334x296
Select picture or schematic to display from thumbnails on the right and click for download.
For model Inconnu / Unknown 1, Echo-Radio; Louvain / Leuven:
Zur Verfügung gestellt von Curt Schreiber.

Country:  Belgium
Manufacturer / Brand:  Echo-Radio; Louvain / Leuven
Year: 1936 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 6D6 6A7 6D6 75 EM1 42 42 80
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 25 cm = 9.8 inch
Power out
from Radiomuseum.org Model: Inconnu / Unknown 1 - Echo-Radio; Louvain / Leuven
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 500 x 470 x 320 mm / 19.7 x 18.5 x 12.6 inch

Model page created by Mark Hippenstiel. See "Data change" for further contributors.



All listed radios etc. from Echo-Radio; Louvain / Leuven
Here you find 3 models, 3 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
