For model Amplifier HF-52, EICO (Electronic Instrument Co.Inc.) Brooklyn:
Sams photofact.

Country:  United States of America (USA)
Manufacturer / Brand:  EICO (Electronic Instrument Co.Inc.) Brooklyn
Year: 1959 ? Category: Audio Amplifier or -mixer
Valves / Tubes 7: ECC83 EC90 ECC83 6CG7 EL34 EL34 GZ34
Main principle Audio-Amplification
Wave bands - without
Details Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker - This model requires external speaker(s).
Power out 50 W (unknown quality)
from Radiomuseum.org Model: Amplifier HF-52 - EICO Electronic Instrument Co.
Material Metal case
Shape Tablemodel, with any shape - general.
Notes

AC operated audio amplifier.

Phono equalization Col / Lon / RIAA / Am 78 / Eur 78.

Output stage identical to Eico HF-50.

Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 483 folder 6 date 5-60)

Model page created by Peter Hoddow. See "Data change" for further contributors.
