Filigran W579M

Filigran W579M; Elbia GmbH; (ID = 120899) Radio

Filigran W579M; Elbia GmbH; (ID = 1898158) Radio

Filigran W579M; Elbia GmbH; (ID = 1898159) Radio
Filigran W579M; Elbia GmbH; (ID = 1021056) Radio Filigran W579M; Elbia GmbH; (ID = 108884) Radio
Filigran W579M; Elbia GmbH; (ID = 108885) Radio Filigran W579M; Elbia GmbH; (ID = 108886) Radio
Filigran W579M; Elbia GmbH; (ID = 120905) Radio Filigran W579M; Elbia GmbH; (ID = 108882) Radio
Filigran W579M; Elbia GmbH; (ID = 1289293) Radio Filigran W579M; Elbia GmbH; (ID = 1289294) Radio
Filigran W579M; Elbia GmbH; (ID = 1289295) Radio Filigran W579M; Elbia GmbH; (ID = 1399997) Radio
Use red slider bar for more.
Filigran W579M; Elbia GmbH; (ID = 1021056) Radio
Elbia GmbH;: Filigran W579M [Radio] ID = 1021056 729x498
Select picture or schematic to display from thumbnails on the right and click for download.
For model Filigran W579M, Elbia GmbH; Schönebeck/Elbe (Ostd.):
Bild von Wolfgang Bauer.

Country:  Germany
Manufacturer / Brand:  Elbia GmbH; Schönebeck/Elbe (Ostd.)
alternative name

Calbe
Brand
VEB Elbia; Schönebeck
Year: 1954–1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: EF85 ECC91 or EC92 ECH81 EF85 6E5_DDR or EM11 EABC80 EL11 EZ12
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz
Tuned circuits 7 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Filigran W579M - Elbia GmbH; Schönebeck/Elbe
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 610 x 400 x 300 mm / 24 x 15.7 x 11.8 inch
Notes Verbesserter UKW-Tuner Elbia-Eigenkonstruktion. Ab Okt.1955 auch mit Fernsehton B.I+III aber nicht jedes Gerät, obwohl die Taste dazu existiert (Zusatzgerät zum Einbau mit 2x EF80). 8 Tasten, linke Taste 0 ohne elektr. Funktion.
Net weight (2.2 lb = 1 kg) 15.5 kg / 34 lb 2.3 oz (34.141 lb)
Price in first year of sale 543.00 DM
Collectors' prices
Source of data Gebrauchswaren-Katalog 1954 / Radiokatalog Band 2, Ernst Erb
Mentioned in Die Geschichte der Rundfunkindustrie der DDR Band 1 1945 - 1967
Literature/Schematics (1) -- Collector info (Sammler) (Jahresübersicht Radio und Fernsehen 1955)

Model page created by Steffen Bartusch. See "Data change" for further contributors.
