• Country
• Italy

• Manufacturer / Brand
• Electa Radio, A. Galimberti; Milano

• Year
• 1946–1948

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 167614

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH4 EF9 EBC3 EL3 EM4 AZ1

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110-220 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet.

• Material
• Wooden case

• from Radiomuseum.org
• Model: 656 - Electa Radio, A. Galimberti;

• Shape
• Tablemodel, low profile (big size).

• Notes
• Gamme d'onda: 2 medie e 3 corte. Simile al mod. ER656L nella forma; questo ha però la scala parlante a sfondo nero.

  Wave bands: 2x BC, 3x SW.

• Source of data
• Guida Pratica Antique Radio III (2000)

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
