A.F. Generator 1115 / TR-0105

A.F. Generator 1115 / TR-0105; EMG, Orion-EMG, (ID = 799123) Equipment A.F. Generator 1115 / TR-0105; EMG, Orion-EMG, (ID = 799126) Equipment
A.F. Generator 1115 / TR-0105; EMG, Orion-EMG, (ID = 799127) Equipment A.F. Generator 1115 / TR-0105; EMG, Orion-EMG, (ID = 799124) Equipment
A.F. Generator 1115 / TR-0105; EMG, Orion-EMG, (ID = 799128) Equipment A.F. Generator 1115 / TR-0105; EMG, Orion-EMG, (ID = 799129) Equipment
A.F. Generator 1115 / TR-0105; EMG, Orion-EMG, (ID = 799130) Equipment A.F. Generator 1115 / TR-0105; EMG, Orion-EMG, (ID = 799131) Equipment
A.F. Generator 1115 / TR-0105; EMG, Orion-EMG, (ID = 913081) Equipment A.F. Generator 1115 / TR-0105; EMG, Orion-EMG, (ID = 1659674) Equipment
Use red slider bar for more.
A.F. Generator 1115 / TR-0105; EMG, Orion-EMG, (ID = 799123) Equipment
EMG, Orion-EMG,: A.F. Generator 1115 / TR-0105 [Equipment] ID = 799123 933x475
Select picture or schematic to display from thumbnails on the right and click for download.
For model A.F. Generator 1115 / TR-0105, EMG, Orion-EMG, Elektronikus Mérökészülélek Gyára; Budapest:
Thanks for Mr.Leiszt János, Hungary!

Country:  Hungary
Manufacturer / Brand:  EMG, Orion-EMG, Elektronikus Mérökészülélek Gyára; Budapest
Year: 1969–1977 Category: Service- or Lab Equipment
Valves / Tubes 6: EL84 EF80 EF86 ECC82 EL34 EL34
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out 5 W (unknown quality)
from Radiomuseum.org Model: A.F. Generator 1115 / TR-0105 - EMG, Orion-EMG, Elektronikus M
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 436 x 180 x 360 mm / 17.2 x 7.1 x 14.2 inch
Notes

20 Hz-20 kHz (6 band), Uout: 0-4 V.

4 rectifiers diodes SIEK-7.

Net weight (2.2 lb = 1 kg) 18 kg / 39 lb 10.4 oz (39.648 lb)
Source of data -- Original prospect or advert
Literature/Schematics (1) MTA Kölcsönmüszerek Jegyzéke, Bp.1983

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
