• Country
• Denmark

• Manufacturer / Brand
• Eltra; Frederiksberg

• Year
• 1963–1965

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 225965

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECC85 EF184 EF184 ECC85 EL86

• Main principle
• Superheterodyne (common)

• Wave bands
• FM Broadcast Band Only

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: Bella Musica 1015 - Eltra; Frederiksberg

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 405 x 167 x 265 mm / 15.9 x 6.6 x 10.4 inch

• Notes

• Record player: 4-speed Monarch

• Author
• Model page created by Timo Rantasaari. See "Data change" for further contributors.
