• Country
• United States of America (USA)

• Manufacturer / Brand
• Emerson Radio & Phonograph Corp.; New York, NY

• Year
• 1958 ?

• Category
• Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

• Radiomuseum.org ID
• 184496

• • alternative name: Emerson Television

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 17

• Valves / Tubes
• 3CB6 5AM8 12BY7A 5U8 3AV6 12C5 6CG7 12W6GT 6CG7 25DN6 or 25CD6GB 12AX4GTA 1B3GT 5AT8 3BC5 3BE6 3BA6 21CBP4A

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110 - 120 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: 1290 Ch= 120386H - Emerson Radio & Phonograph

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• Emerson TV-Phonoradio Model 1290
  Aailable in Mahogany or Blonde grained finishes

  21 " b/w TV with US standard VHF tuner, tuning range channels 2 thru 13 VHF, 14 thru 83 UHF.
  Models 1288, 1289, 1290 and 1291 use AM-Tuner and Emerson Record Changer #819117.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 7-58, Set 406, Folder 2)

• Literature/Schematics (2)
• Photofact Folder, Howard W. SAMS (Set 389 Folder 16-S dated 2-58)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
