C140LW Ch= CLW

C140LW Ch= CLW; Emerson Radio & (ID = 284235) Radio
Use red slider bar for more.
C140LW Ch= CLW; Emerson Radio & (ID = 284235) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Emerson Radio & Phonograph Corp.; New York, NY
alternative name

Emerson Television
Year: 1938 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 6K7 6A8 6K7 6R7 6G5 6C5 or 6J7 6F6 or 6L6 5W4
Main principle Superhet with RF-stage; ZF/IF 456 kHz; 3 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: C140LW Ch= CLW - Emerson Radio & Phonograph
Notes LW(150-375kHz), BC(540-1800kHz) and SW(5.5-18.0MHz) bands. tuning eye. Models above serial number 848410 use 6J7 and 6L6.
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 7 = 1936 and before
Mentioned in Rider's Perpetual, Volume 9 = 1938 and before
