Record 3
Emud, Ernst Mästling; Ulm
- Country
- Germany
- Manufacturer / Brand
- Emud, Ernst Mästling; Ulm
- Year
- 1930
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 194627
Katalogbild des Herstellers
Bild aus Gebrauchsanweisung.
Katalog Fa. Anode ca. 1930
- Number of Tubes
- 4
- Valves / Tubes
- Arcotron301 Arcotron201 RE134 RGN354
- Main principle
- TRF with regeneration
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Metal case
- from Radiomuseum.org
- Model: Record 3 - Emud, Ernst Mästling; Ulm
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 220 x 150 x 170 mm / 8.7 x 5.9 x 6.7 inch
- Notes
-
Preis einschliesslich Röhren, ohne Röhren RM 53,-
In gleicher äusserer Ausführung als Emud Record mit 3 Röhren ohne Arcotron gefertigt.
- Net weight (2.2 lb = 1 kg)
- 3.5 kg / 7 lb 11.3 oz (7.709 lb)
- Price in first year of sale
- 90.00 RM
- Mentioned in
- Anode, Nachtrag (Nov. 1930) zum Radio Haupt Katalog 1930
- Author
- Model page created by Wolfgang Bauer. See "Data change" for further contributors.
- Other Models
-
Here you find 421 models, 327 with images and 231 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Emud, Ernst Mästling; Ulm
