Volks-Super U.L.M (Ulm) 44-W

Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 907220) Radio
Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 924675) Radio Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 12063) Radio
Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 12064) Radio Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 1068963) Radio
Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 1068965) Radio Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 1068966) Radio
Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 1068967) Radio Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 1068968) Radio
Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 1068969) Radio Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 2341133) Radio
Use red slider bar for more.
Volks-Super U.L.M 44-W; Emud, Ernst Mästling (ID = 924675) Radio
Emud, Ernst Mästling: Volks-Super U.L.M 44-W [Radio] ID = 924675 933x619
Select picture or schematic to display from thumbnails on the right and click for download.
For model Volks-Super U.L.M (Ulm) 44-W, Emud, Ernst Mästling; Ulm

Country:  Germany
Manufacturer / Brand:  Emud, Ernst Mästling; Ulm
Year: 1953/1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: EC92 ECH81 ECL113
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Tuned circuits 4 AM circuit(s)     5 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 120; 150; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
Power out
from Radiomuseum.org Model: Volks-Super U.L.M 44-W - Emud, Ernst Mästling; Ulm
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 420 x 285 x 190 mm / 16.5 x 11.2 x 7.5 inch
Notes ZF-Audion.
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Price in first year of sale 140.00 DM
Source of data Kat.d.Rundf.GrossH.1953/54 / Radiokatalog Band 1, Ernst Erb


All listed radios etc. from Emud, Ernst Mästling; Ulm
Here you find 417 models, 320 with images and 221 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
