All Transistor Silver

All Transistor Silver ; FAART F.A.A.R.T.; (ID = 2318775) Radio All Transistor Silver ; FAART F.A.A.R.T.; (ID = 2318773) Radio
All Transistor Silver ; FAART F.A.A.R.T.; (ID = 2318774) Radio All Transistor Silver ; FAART F.A.A.R.T.; (ID = 2318776) Radio
All Transistor Silver ; FAART F.A.A.R.T.; (ID = 2318777) Radio All Transistor Silver ; FAART F.A.A.R.T.; (ID = 2318778) Radio
All Transistor Silver ; FAART F.A.A.R.T.; (ID = 2318779) Radio
Use red slider bar for more.
All Transistor Silver ; FAART F.A.A.R.T.; (ID = 2318775) Radio
FAART F.A.A.R.T.;: All Transistor Silver [Radio] ID = 2318775 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model All Transistor Silver, FAART (F.A.A.R.T.); Milano

Country:  Italy
Manufacturer / Brand:  FAART (F.A.A.R.T.); Milano
Year: 1965 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: AF116 AF117 AF117 AC132 AC127 OC71 OC71
Main principle Superheterodyne (common)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: All Transistor Silver - FAART F.A.A.R.T.; Milano
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 153 x 85 x 45 mm / 6 x 3.3 x 1.8 inch
Notes

controllo volume - antenna interna in ferrite.

Net weight (2.2 lb = 1 kg) 0.550 kg / 1 lb 3.4 oz (1.211 lb)

Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
