Record - magnetofono

Record - magnetofono ; Faro Nuova Faro; (ID = 1632763) R-Player Record - magnetofono ; Faro Nuova Faro; (ID = 1632766) R-Player
Record - magnetofono ; Faro Nuova Faro; (ID = 1632769) R-Player Record - magnetofono ; Faro Nuova Faro; (ID = 1632770) R-Player
Record - magnetofono ; Faro Nuova Faro; (ID = 1632771) R-Player Record - magnetofono ; Faro Nuova Faro; (ID = 2313042) R-Player
Use red slider bar for more.
Record - magnetofono ; Faro Nuova Faro; (ID = 1632763) R-Player
Faro Nuova Faro;: Record - magnetofono [R-Player] ID = 1632763 900x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model Record - magnetofono, Faro (Nuova Faro); Italy

Country:  Italy
Manufacturer / Brand:  Faro (Nuova Faro); Italy
Year: 1960 ?? Category: Sound/Video Recorder and/or Player
Valves / Tubes 2: ECC83 ECL82
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 17 cm = 6.7 inch
Power out
from Radiomuseum.org Model: Record - magnetofono - Faro Nuova Faro; Italy
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 300 x 160 x 230 mm / 11.8 x 6.3 x 9.1 inch
Collectors' prices

Model page created by Vittorio Scandagliato. See "Data change" for further contributors.



All listed radios etc. from Faro (Nuova Faro); Italy
Here you find 14 models, 12 with images and 3 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
