F43T180U
Fenno, Helsinki - see also Philips
- Country
- Finland
- Manufacturer / Brand
- Fenno, Helsinki - see also Philips
- Year
- 1958
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 221648
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 19
- Valves / Tubes
- PCC88 PCF80 EF80 EF80 EF80 PCF80 EF80 PCL82 PCF80 ECH81 PCF80 PCF80 PL81 PY81 DY87 PCL82 PY82 PY82 AW43-80
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 14 cm = 5.5 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: F43T180U - Fenno, Helsinki - see also
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 475 x 402 x 390 mm / 18.7 x 15.8 x 15.4 inch
- Notes
- 17" B/W television, VHF tuner.
- Author
- Model page created by Jouko Laukkanen. See "Data change" for further contributors.
