• Country
• Finland

• Manufacturer / Brand
• Fenno, Helsinki - see also Philips

• Year
• 1939 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 264071

• Number of Tubes
• 3

• Valves / Tubes
• EF9 EL3N AZ1

• Main principle
• TRF with regeneration

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 225; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: SOYP - Fenno, Helsinki - see also

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 495 x 258 x 192 mm / 19.5 x 10.2 x 7.6 inch

• Author
• Model page created by Timo Rantasaari. See "Data change" for further contributors.

• Other Models

• Here you find 149 models, 129 with images and 23 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
