AM/FM Radiogram RG27

AM/FM Radiogram RG27; Fidelity Radio Ltd.; (ID = 2321941) Radio

AM/FM Radiogram RG27; Fidelity Radio Ltd.; (ID = 2321942) Radio

AM/FM Radiogram RG27; Fidelity Radio Ltd.; (ID = 2321943) Radio

AM/FM Radiogram RG27; Fidelity Radio Ltd.; (ID = 2321944) Radio
Use red slider bar for more.
AM/FM Radiogram RG27; Fidelity Radio Ltd.; (ID = 2321941) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Fidelity Radio Ltd.; London
Year: 1962 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EL84 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 470/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 4 W (unknown quality)
from Radiomuseum.org Model: AM/FM Radiogram RG27 - Fidelity Radio Ltd.; London
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes

An AC mains three band AM/FM radiogram covering MW (194-545 metres), LW (1200-2000 metres) and VHF (87.5-99.5 MHz), and fitted with a four speed BSR UA14 autochanger with TC8M cartridge. Sockets for external FM aerial, AM aerial, earth, tape recorder and external loudspeaker. Released September 1962.

Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1696 dated 27 March 1965)

Model page created by Howard Craven. See "Data change" for further contributors.
