FM-1000

FM-1000; Fisher Radio; New (ID = 1475013) Radio FM-1000; Fisher Radio; New (ID = 657331) Radio
FM-1000; Fisher Radio; New (ID = 657332) Radio FM-1000; Fisher Radio; New (ID = 657333) Radio
FM-1000; Fisher Radio; New (ID = 657334) Radio FM-1000; Fisher Radio; New (ID = 657335) Radio
FM-1000; Fisher Radio; New (ID = 657336) Radio FM-1000; Fisher Radio; New (ID = 657337) Radio
FM-1000; Fisher Radio; New (ID = 1475012) Radio FM-1000; Fisher Radio; New (ID = 1475014) Radio
Use red slider bar for more.
FM-1000; Fisher Radio; New (ID = 1475013) Radio
Fisher Radio; New: FM-1000 [Radio] ID = 1475013 933x413
Select picture or schematic to display from thumbnails on the right and click for download.
For model FM-1000, Fisher Radio; New York (NY):
Ebay Seller: jbee086 Item Number: 111064723554 Fisher FM1000 Front View #1

Country:  United States of America (USA)
Manufacturer / Brand:  Fisher Radio; New York (NY)
Year: 1962 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 18: 6DJ8 or ECC88 6CW4 6CW4 6BL8 or ECF80 6AU6 or EF94 6AU6 or EF94 6AU6 or EF94 6AU6 or EF94 6BN6 6AU6 or EF94 6DJ8 or ECC88 6DJ8 or ECC88 6267 or EF86 6267 or EF86 6DJ8 or ECC88 12AT7 or ECC81 12AX7 or ECC83 12AT7 or ECC81
Main principle Superhet with RF-stage
Wave bands FM Broadcast Band Only
Details
Power type and voltage Alternating Current supply (AC) / Either 50-60 cycles, 105-120V or 50 cycles, 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: FM-1000 - Fisher Radio; New York NY
Material Various materials
Shape Book-shelf unit.
Dimensions (WHD) 430 x 123 x 318 mm / 16.9 x 4.8 x 12.5 inch
Notes

The Fisher FM-1000 is an AC operated, 18 tube FM stereo tuner, with Muting, AFC, Signal Strength meter and VU meter. This model is similar to the FMR-1, with the FMR-1 being a rack mounted model targeted for commercial use and the FM-1000 being a bookshelf type unit (mounted in an optional wooden cabinet) targeted for home use.


AF output voltage 2 volts.
Stereo Mono automatic.
Number of circuits 6ZF, 5 limiter. 18 tubes, 15 diodes.
Distributed by Messrs. Elect

Price in first year of sale 2'840.00 DM
Mentioned in HiFi Jahrbuch 1963/64 Seite 90
Literature/Schematics (1) Funk-Technik (FT) (19/1962, S. 656 / Neuvorstellung, Messe Zürich)

Model page created by Franz Scharner. See "Data change" for further contributors.
