502; Fridor Fabrieken, N. (ID = 239140) Radio
Fridor Fabrieken, N.: 502 [Radio] ID = 239140 640x424
Select picture or schematic to display from thumbnails on the right and click for download.
For model 502, Fridor Fabrieken, N.V.; Den Haag

Country:  Netherlands
Manufacturer / Brand:  Fridor Fabrieken, N.V.; Den Haag
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH21 ECH21 EBL21 AZ1
Main principle Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out 4 W (unknown quality)
from Radiomuseum.org Model: 502 - Fridor Fabrieken, N.V.; Den
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 600 x 390 x 250 mm / 23.6 x 15.4 x 9.8 inch
Notes
Net weight (2.2 lb = 1 kg) 11 kg / 24 lb 3.7 oz (24.229 lb)
Price in first year of sale 296.00 Hfl
Source of data Technisch- Commercieel - Radio Vademecum Staleman

Model page created by John Koster. See "Data change" for further contributors.
