G114 /U

G114 /U; Geloso SA; Milano (ID = 1884912) Radio
G114 /U; Geloso SA; Milano (ID = 1840476) Radio G114 /U; Geloso SA; Milano (ID = 1829754) Radio
G114 /U; Geloso SA; Milano (ID = 1829757) Radio G114 /U; Geloso SA; Milano (ID = 1829758) Radio
G114 /U; Geloso SA; Milano (ID = 1829761) Radio G114 /U; Geloso SA; Milano (ID = 1840477) Radio
G114 /U; Geloso SA; Milano (ID = 1992696) Radio G114 /U; Geloso SA; Milano (ID = 1992697) Radio
G114 /U; Geloso SA; Milano (ID = 1992698) Radio G114 /U; Geloso SA; Milano (ID = 2555907) Radio
Use red slider bar for more.
G114 /U; Geloso SA; Milano (ID = 1840476) Radio
Geloso SA; Milano: G114 /U [Radio] ID = 1840476 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model G114 /U, Geloso SA; Milano

Country:  Italy
Manufacturer / Brand:  Geloso SA; Milano
Year: 1955/1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCH81 UF41 UBC41 UL41 1629 UY41
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12.5 cm = 4.9 inch
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: G114 /U - Geloso SA; Milano
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 505 x 275 x 210 mm / 19.9 x 10.8 x 8.3 inch
Notes

Serie ANIE.

Net weight (2.2 lb = 1 kg) 5.350 kg / 11 lb 12.5 oz (11.784 lb)
Price in first year of sale 29'000.00 ITL
Mentioned in Catalogo ANIE (1955-56)

Model page created by Marco Gilardetti. See "Data change" for further contributors.



All listed radios etc. from Geloso SA; Milano
Here you find 847 models, 762 with images and 603 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Geloso SA; Milano: G114 /U
Threads: 1 | Posts: 1
Hits: 1617     Replies: 0
geloso: G114 /U schema elettrico;
Biagio Laureti
17.Sep.15
  1

In merito alle valvole utilizzate sul ricevitore G114U dispongo delle seguenti note riportate sul Catalogo Antique Radio in merito al ricevitore:

G114U serie ANIE:
Mobile identicico al G114
Note: come il modello G114 ma con la valvola UCH81 al posto della UCH42

Saluti Biagio





Geloso SA; Milano: G114 /U
