For model GTV-8/234, Geloso SA; Milano:
Televisore Geloso GTV-8/234.
Catalogo Geloso, primavera 1969

Country:  Italy
Manufacturer / Brand:  Geloso SA; Milano
Year: 1969 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 12: 6DS4 PCF801 EF183 PFL200 PCH200 PCL86 PCF802 PCL85 PL504 PY88 DY87 A59-23W
Semiconductors (the count is only for transistors) 6: AF239 AF139 AF121 AF121 AF118 AF121
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: GTV-8/234 - Geloso SA; Milano
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 580 x 430 x 300 mm / 22.8 x 16.9 x 11.8 inch
Notes

Televisore a 23" a nuvistor, transistor e valvole.

Price in first year of sale 148'000.00 ITL
Mentioned in -- Original prospect or advert (Catalogo Geloso, primavera 1969)
Literature/Schematics (1) -- Schematic (Schemario di Apparecchi Televisivi Vol. XXI° R. Rosati.)

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
