GTV-8F170

GTV-8F170; Geloso SA; Milano (ID = 1009689) Television

GTV-8F170; Geloso SA; Milano (ID = 1009690) Television

GTV-8F170; Geloso SA; Milano (ID = 1009691) Television

GTV-8F170; Geloso SA; Milano (ID = 1009692) Television

GTV-8F170; Geloso SA; Milano (ID = 1009693) Television

GTV-8F170; Geloso SA; Milano (ID = 1009694) Television

GTV-8F170; Geloso SA; Milano (ID = 1009695) Television

GTV-8F170; Geloso SA; Milano (ID = 1009696) Television

GTV-8F170; Geloso SA; Milano (ID = 1009697) Television

GTV-8F170; Geloso SA; Milano (ID = 1009698) Television
GTV-8F170; Geloso SA; Milano (ID = 1525372) Television GTV-8F170; Geloso SA; Milano (ID = 1525373) Television
GTV-8F170; Geloso SA; Milano (ID = 1525374) Television GTV-8F170; Geloso SA; Milano (ID = 2186390) Television
Use red slider bar for more.
GTV-8F170; Geloso SA; Milano (ID = 1525372) Television
Geloso SA; Milano: GTV-8F170 [Television] ID = 1525372 900x752
Select picture or schematic to display from thumbnails on the right and click for download.
For model GTV-8F170, Geloso SA; Milano:
Propria collezione

Country:  Italy
Manufacturer / Brand:  Geloso SA; Milano
Year: 1968–1971 Category: Television Receiver (TV) or Monitor
Valves / Tubes 12: 6DS4 PCF801 EF183 PFL200 PCH200 PCL86 PCF802 PCL85 PL504 PY88 DY87 RT44B4
Semiconductors (the count is only for transistors) 6: AF239 AF139 AF121 AF121 AF118 AF121
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: GTV-8F170 - Geloso SA; Milano
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 490 x 360 x 200 mm / 19.3 x 14.2 x 7.9 inch
Notes

Cinescopio da 17". Maniglia per trasporto.

Price in first year of sale 164'000.00 ITL
Mentioned in Bollettino Tecnico Geloso (n. 108-109 inverno 1968-primavera 1969)
Literature/Schematics (1) Catalogo ANIE (1970-71)
Literature/Schematics (2) -- Original prospect or advert (Catalogo Geloso, primavera 1969)

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
