GTV-8F246

GTV-8F246; Geloso SA; Milano (ID = 1011949) Television

GTV-8F246; Geloso SA; Milano (ID = 1011952) Television

GTV-8F246; Geloso SA; Milano (ID = 1011954) Television

GTV-8F246; Geloso SA; Milano (ID = 1011955) Television

GTV-8F246; Geloso SA; Milano (ID = 1011959) Television

GTV-8F246; Geloso SA; Milano (ID = 1011960) Television

GTV-8F246; Geloso SA; Milano (ID = 1011961) Television

GTV-8F246; Geloso SA; Milano (ID = 1011963) Television

GTV-8F246; Geloso SA; Milano (ID = 1011965) Television

GTV-8F246; Geloso SA; Milano (ID = 1011966) Television
GTV-8F246; Geloso SA; Milano (ID = 1635955) Television GTV-8F246; Geloso SA; Milano (ID = 1635956) Television
GTV-8F246; Geloso SA; Milano (ID = 1635957) Television GTV-8F246; Geloso SA; Milano (ID = 2186418) Television
Use red slider bar for more.
GTV-8F246; Geloso SA; Milano (ID = 1635955) Television
Geloso SA; Milano: GTV-8F246 [Television] ID = 1635955 634x476
Select picture or schematic to display from thumbnails on the right and click for download.
For model GTV-8F246, Geloso SA; Milano

Country:  Italy
Manufacturer / Brand:  Geloso SA; Milano
Year: 1969 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 12: 6DS4 PCF801 EF183 PFL200 PCH200 PCL86 PCF802 PCL85 PL504 PY88 DY87 A59-23W
Semiconductors (the count is only for transistors) 6: AF239 AF139 AF121 AF121 AF118 AF121
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: GTV-8F246 - Geloso SA; Milano
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 700 x 520 x 360 mm / 27.6 x 20.5 x 14.2 inch
Notes

Televisore 23", a 10 valvole (+CRT), un nuvistor e 14 semiconduttori. Presa per telecomando a filo n. 7798 (opzionale). Presa per registratore. Mobile di lusso.

Price in first year of sale 199'000.00 ITL
Mentioned in -- Original prospect or advert (Catalogo Geloso, primavera 1969)
Literature/Schematics (1) -- Schematic (Schemario di Apparecchi Televisivi Vol. XXI° R. Rosati.)

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
