Sideral G3310

Sideral G3310; Geloso SA; Milano (ID = 1338618) Radio
Sideral G3310; Geloso SA; Milano (ID = 2521873) Radio Sideral G3310; Geloso SA; Milano (ID = 1583288) Radio
Sideral G3310; Geloso SA; Milano (ID = 2521874) Radio Sideral G3310; Geloso SA; Milano (ID = 2521875) Radio
Sideral G3310; Geloso SA; Milano (ID = 1583287) Radio Sideral G3310; Geloso SA; Milano (ID = 1583285) Radio
Sideral G3310; Geloso SA; Milano (ID = 1583284) Radio Sideral G3310; Geloso SA; Milano (ID = 802445) Radio
Sideral G3310; Geloso SA; Milano (ID = 1583277) Radio Sideral G3310; Geloso SA; Milano (ID = 1583279) Radio
Use red slider bar for more.
Sideral G3310; Geloso SA; Milano (ID = 2521873) Radio
Geloso SA; Milano: Sideral G3310 [Radio] ID = 2521873 1024x635
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sideral G3310, Geloso SA; Milano

Country:  Italy
Manufacturer / Brand:  Geloso SA; Milano
Year: 1965 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCL82 UBF89 UCH81 DM70
Main principle Superheterodyne (common)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Sideral G3310 - Geloso SA; Milano
Material Various materials
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 250 x 150 x 120 mm / 9.8 x 5.9 x 4.7 inch
Notes Gamme d'onda: onde medie e 4 onde corte.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Price in first year of sale 22'500.00 ITL
Mentioned in Catalogo ANIE 1965-66

Model page created by Eduard Abfalterer. See "Data change" for further contributors.



All listed radios etc. from Geloso SA; Milano
Here you find 842 models, 757 with images and 602 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
