BC675

BC675; Genalex, BGE brand, (ID = 767356) Radio
Use red slider bar for more.
BC675; Genalex, BGE brand, (ID = 767356) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Australia
Manufacturer / Brand:  Genalex, BGE (brand), British General Electric Co. Pty Ltd.; Sydney, NSW.
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1A7G 1N5G 1H5G 1C5G
Main principle Super-Heterodyne (Super in general); ZF/IF 458 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 90 & 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: BC675 - Genalex, BGE brand, British
Shape Tablemodel, with any shape - general.
Notes This model uses the same chassis as the Tasma model 675.
Circuit diagram reference Australian Official Radio Service Manual Vol. III
Literature/Schematics (1) Mingay's Radio Diagram & I.F. Index

Model page created by Stuart Irwin. See "Data change" for further contributors.
