BC4040

BC4040; GEC, General (ID = 1278811) Radio

BC4040; GEC, General (ID = 1278812) Radio

BC4040; GEC, General (ID = 1278814) Radio
BC4040; GEC, General (ID = 1148722) Radio BC4040; GEC, General (ID = 1278851) Radio
BC4040; GEC, General (ID = 1278819) Radio BC4040; GEC, General (ID = 1278820) Radio
BC4040; GEC, General (ID = 1468348) Radio BC4040; GEC, General (ID = 1468349) Radio
Use red slider bar for more.
BC4040; GEC, General (ID = 1148722) Radio
GEC, General: BC4040 [Radio] ID = 1148722 933x613
Select picture or schematic to display from thumbnails on the right and click for download.
For model BC4040, GEC, General Electric Co.; London

Country:  Great Britain (UK)
Manufacturer / Brand:  GEC, General Electric Co.; London
Brand

Gecophone
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: X63 KTW61 DL63 KT61 U50
Main principle Super-Heterodyne (Super in general); ZF/IF 456 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 190-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: BC4040 - GEC, General Electric Co.;
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 18.5 x 11 x 9 inch / 470 x 279 x 229 mm
Notes Push buttons for 6 pre-set rado stations. The BC4040L is the same but has an additional low voltage AC mains option. Same cabinet as the BC4046 battery model.
Collectors' prices
Source of data Radio! Radio!
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (429)

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.



All listed radios etc. from GEC, General Electric Co.; London
Here you find 415 models, 244 with images and 231 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
