• Country
• Germany

• Manufacturer / Brand
• Graetz, Altena (Westfalen)

• Year
• 1973/1974

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 129288

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• PCF802 PL504 PCL805 PY88 PL95 A51-10W

• Number of Transistors
• 15

• Semiconductors
• 1N4148 1N4148 1N4148 1N4148 1N4148 1N4148 1N4148 1N4148 1N4148 1N4148 1N60 BA157 BA182 BA182 BA182 BA243 BA243 BA243 BAV20 BAV20 BAV21 BAV21 BB105 BB105 BB105 BB142 BB142 BB142 BB142 BY133 or. BY127 BY133 or. BY127 TV20 ZTK33 ZY13 AF106 AF106 AF239 AF239 AF267 BC171 BC172 BC172 BC172 BC172 BF137 BF196 BF198 BF199 BF305 TBA120

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Peer Electronic 2228 - Graetz, Altena Westfalen

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 580 x 427 x 293 mm / 22.8 x 16.8 x 11.5 inch

• Notes
• • 51 cm Portable
  • 1 IC
  • 34 Dioden
  • VHF/UHF-Tuner
  • Fernbedienung FB 1000.

• Net weight (2.2 lb = 1 kg)
• 18 kg / 39 lb 10.4 oz (39.648 lb)

• Mentioned in
• -- Original-techn. papers. (Weiler Angebot 1973/74)

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
